Step 1
Remove the screen on the top black holding plate.
To remove the lens you will need the flat head screw driver. Ease it out gently supporting the lens at the base.

This video shows how to install Anderson Powerpole connectors onto a power cable / wire. These connectors are very popular with the amateur / ham radio community as well as emergency and first.

Step2
With the lens removed, release the clips and insert the halogen bulb. Note the bulb can only go in one way.
Now thread the wires through the welch plug and using the connectors supplied attach one to the earth and one to the active which is the wire coming from the bulb.
With the front still off undo the main bolt and flip it over so that the head is inside the lamp case.

Narva Ultima 175 Installation Instructions Pdf

• View online Installation and operation manual for Humminbird PiranhaMAX 165 Fish Finder or simply click Download button to examine the Humminbird PiranhaMAX 165 guidelines offline on your desktop or laptop computer. PiranhaMAX 175, PiranhaMAX 176ci, PiranhaMAX 195c, PiranhaMAX 196ci. Humminbird Ultima Operation Manual Operation.
• Just installed a set of Narva ultima 175 lights on my PJ Ford Ranger with the narva driving light harness ht-harness.

Step3
Reasemble the lens and backing making sure that it is closed securely. Now choose your mounting position on your vehicle, we choose to mount them on the using the spotlight mounting brackets.
Following the wiring diagram on the back of the package trace your cable through the engine bay into the cabin and mount the switch.
Also remember to earth the lights.

Step4
Test the lights.

Note Narva recommends installing a fuse between the battery and the relay active wire.

Narva Ultima 175 Installation Instructions 2017

Narva Ultima 175 Installation Instructions Download

Further notes

Narva Ultima 175 Installation Instructions 2016

4x4 Australia Magazine driving light comparasion recently of all the major brands of spotlights. The Narva Ultimas were rated as 'the stand-out
performers'.

Other Ultima lamps available

71610 - 160mm x 115mm Rect Long Range
71640 - 175mm dia Broad Beam (as tested)
71650 - 175mm dia Pencil Beam
71660 - 175mm Combo kit Broad/Pencil

All kits and lamps manufactured in Sweden.
